Network Camera User Manual
14
2. Check the device status from the device list, and select the inactive device.
SADP Interface
Note:
The SADP software supports activating the camera in batch. Refer to the user manual
of SADP software for details.
3. Create and input the password in the password field, and confirm the password.
A password with user name in it is not allowed.
STRONG PASSWORD RECOMMENDED– We highly recommend
you create a strong password of your own choosing (using a minimum
of 8 characters, including at least three of the following categories:
upper case letters, lower case letters, numbers, and special characters) in
order to increase the security of your product. And we recommend you
reset your password regularly, especially in the high security system,
resetting the password monthly or weekly can better protect your
product.
Note:
You can enable the Hik-Connect service for the device during activation.
4. Click Activate to start activation.
You can check whether the activation is completed on the popup window. If activation
Select inactive device.
Input and confirm
password.

HIKVISION DS-2CD2347G1-L Specifications

General

Max. Resolution	2688 × 1520
Focal Length	2.8 mm
Day/Night	ICR
Supplement Light Range	30 m
Video Compression	H.265+/H.265/H.264+/H.264
Wide Dynamic Range (WDR)	120 dB
Ingress Protection	IP67
Image Sensor	1/2.8" Progressive Scan CMOS
Lens Type	Fixed
Supplement Light Type	IR
Bit Rate (H.265/H.264)	32 Kbps to 16 Mbps
Frame Rate	50 Hz: 25 fps (2688 × 1520); 60Hz: 30 fps (2688 × 1520)
Network Interface	RJ45 (10/100 Base-T)
Power Supply	12 VDC ± 25%
Power Consumption	Max. 7.5 W
Operating Conditions	-30 °C to 60 °C (-22 °F to 140 °F), humidity: ≤ 95%, non-condensing
Weight	0.9 kg
