HIKVISION DS-2CD2532F-IS Quick Operation Guide

Network Mini Dome Camera·Quick Operation Guide
10
10
 No.8 is the audio/alarm cable interface, of which the “I” mark
connects to the alarm input, the “o” mark connects to the
alarm output, the “GND” mark connects the grounding, and the
“A” mark connects the audio output.
 WPS (Wi-Fi Protected Setup, also known as AOSS or QSS) is a
computing standard that attempts to allow easy establishment
of a secure wireless network. Refer to user manual for details.
 A wireless router with the WPS function is required to enable
the WPS function of the camera. Refer the steps below.
Steps:
Press the WPS button on the router. 1.
Press the WPS button (about 2s) on the camera within 120s 2.
you enable the WPS of the router to join in the wireless
network.
 The WPS button works as a reset button only when you
press it when the camera is powering on.
 Press the WPS button on the camera, and then press the
WPS button on the router will establish a connection as
well, and the expire time of WPS connection on the
camera is 120s.
 The link indicator blinks if the wireless connection is
succeeded.

HIKVISION DS-2CD2532F-IS Specifications

General

Fixed focal length	6 mm
Maximum aperture number	2
Pan range	-30 - 30 °
Tilt angle range	0 - 75 °
Angle of rotation	360 °
Camera shutter type	Electronic
Camera shutter speed	1/3 - 1/100000 s
Minimum illumination	0 lx
Field of view (FOV) angle	43.3 °
Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Form factor	Dome
Mounting type	Ceiling
Product color	White
International Protection (IP) code	IP66
Total megapixels	3 MP
Maximum resolution	2048 x 1536 pixels
Supported video modes	1080p
Image quality adjustment	Brightness, Contrast, Saturation
Video compression formats	H.264, M-JPEG
Supported graphics resolutions	1920 x 1080 (HD 1080), 2048 x 1536 (QXGA)
Sensor type	CMOS
Optical sensor size	1/3 \
Password protection type	User
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	128 GB
LED type	IR
Night vision distance	10 m
Cabling technology	10/100Base-T(X)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Number of cameras	1
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
DC output voltage	12
Power source type	PoE
Power consumption (max)	5 W
Audio system	2-way
Audio formats supported	G.711, G.726
Interface	RJ-45
Lens mount interface	M12

Weight and Dimensions

Depth	96.7 mm
Width	99.3 mm
Height	52.8 mm
Weight	600 g
