Network Camera User Manual
28
External Device Settings
2. Check the Enable Supplement Light checkbox to enable the LED Light.
3. Move the slider to adjust the low beam brightness and high bean brightness.
4. Select the mode for LED light. Timing and Auto are selectable.
Timing: The LED will be turned on by the schedule you set. You should set
the Start Time and End Time.
Set Schedule
Auto: The LED will be turned on according to the environment illumination.
5. Click Save to save the settings.
Configuring VCA Resource
Purpose:
The camera has four lens in total. The four lens are named as Camera 01 to Camera
04 clockwise starting from the dial mark 0° to 240° on camera body. The smart events
only work for the camera No. 01 and camera No. 03, or camera No. 02 and camera
No. 04.
VCA Resource Configuration
Steps:
1. Enter VCA Resource configuration interface:
Configuration > System > System Settings > VCA Resource
