HIKVISION DS-2CD7153-E Installation Manual

Installation Manual of Network Mini Dome Camera
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©
10
DS-2CD7133-E
Specification
Model
Parameter
DS-2CD7133-E
VGA 1/4” CMOS Day&Night Weather-proof Vandal-proof Network Mini
Dome Camera
Camera
Image Sensor
1/4” Progressive Scan CMOS
Min. Illumination
0.4 Lux @(F1.2, AGC ON)
0.9Lux @(F1.8, AGC ON)
Electronic Shutter
1/25s ~1/100,000s
Lens
4mm@F1.8 (2.8mm, 6mm, 8mm optional)
Angle of view: 71°(4mm)
Lens Mount
M12
Adjustment
Range
Pan±15°, Tilt0 ~90°, Rotation±15°
Day&Night
Electronic
Compression Standard
Video
Compression
H.264/MJpeg
Bit rate
32 Kbps~8Mbps
Audio
Compression
G.711(G.722.1 optional)
Max. Image
Resolution
640×480
Frame Rate
50HZ: 25fps (640×480)
60HZ: 30fps (640×480)
Image Settings
Saturation, Brightness, Contrast adjustable through client software or web
browser
Network
Storage
Support NAS ( ISCSI optional)
Intelligent Alarm
Motion Detection
Protocols
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, PPPoE, SMTP, NTP
(SNMP, HTTPS, FTP, SIP, SRTP, 802.1x, IPv6 optional )
Basic
Initial Set Button, Anti-flicker, Dual Stream, Heartbeat, Password Protection,
Watermark
Interface
Communication
1RJ45 10M / 100M self-adaptive Ethernet interface

HIKVISION DS-2CD7153-E Specifications

General

Type	IP security camera
PTZ control	-
Day/night mode	Yes
Placement supported	Outdoor
Connectivity technology	Wired
Form factor	Dome
Product color	White
Protection features	Vandal proof
International Protection (IP) code	IP66
Total megapixels	2 MP
Maximum resolution	1600 x 1200 pixels
Supported video modes	720p
Video formats supported	H.264, M-JPEG, MPEG4
Supported graphics resolutions	1280 x 960, 1280 x 720 (HD 720), 1600 x 1200 (UXGA)
Pan range	-15 - 15 °
Tilt angle range	0 - 90 °
Angle of rotation	15 °
Camera shutter speed	1/25 - 1/100000 s
Minimum illumination	0.1 lx
Field of view (FOV) angle	68 °
Sensor type	CMOS
Optical sensor size	1/3 \
Optical zoom	- x
Focus adjustment	1.8
Fixed focal length	2.8 mm
Password protection type	User
Wi-Fi	No
Cabling technology	10/100Base-T(X)
Supported network protocols	TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, Qos (SIP, SRTP
Ethernet LAN (RJ-45) ports	1
DC output voltage	+12V
Power source type	PoE
Power consumption (max)	4 W

Weight and Dimensions

Depth	97.5 mm
Width	99.9 mm
Height	46.5 mm
Weight	250 g
