HIKVISION DS-2CD7253F-EIZ Technical Manual

Hikvision Technical Manual
©2006 – 2012 by HIKVISION. All rights reserved.
3
DS-2CD7253F-E(I)Z(H)(S)
Key Features
 Up to 2 megapixel (1600 x 1200) resolution
 Standard video compression with high compression ratio
 Progressive scan CMOS, capture motion video without incised margin
 Support dual stream, and the sub-stream for mobile surveillance
 Motorized VF lens
 Two-way audio
 Support e-PTZ
 PoE (Power over Ethernet)
 Auto-iris, electronic shutter for different surveillance environments
 Support analog video output for adjustment and installation
 3-axis (pan/tilt/rotation) positioning allows adjustment for optimum camera rotation and position
 Ingress Protection level: IP66
 Impact Protection: IEC60068-2-75 test, Eh, 50J; EN50102, up to IK10
 Other functions: heartbeat, PTZ control, alarm, reset button, mirror, etc.
Specification
Model
Parameter
DS-2CD7253F-E(I)Z(H)(S)
2 Megapixel CMOS Weather-proof Vandal-Proof Network Dome Camera
Camera
Image Sensor
1/3” Progressive Scan CMOS
Min. Illumination
0.5 Lux @(F1.2,AGC ON)
0.8 Lux @(F1.6,AGC ON)
0 Lux with IR
Shutter Speed
1/25 s to 1/100,000 s
