HIKVISION DS-2CD753F-E User Manual

Hikvision Technical Manual
©2006 – 2012 by HIKVISION. All rights reserved.
4
-Z: Motorized VF lens, 2.7-9mm @ F1.2,Angle of view: 101°-30.4°
Lens Mount
Φ14
Auto-iris
DC drive
Angle
Adjustment
Pan:0° - 360°, Tilt: 0° - 75°, Rotation: 0° - 360°
Day & Night
Electronic (-I: IR cut filter with auto switch)
Compression Standard
Video
Compression
H.264/MPEG4/MJPEG
Bit Rate
32 Kbps – 16 Mbps
Audio
Compression
G.711/G.726
Dual Stream
Yes
Max. Resolution
1600 x 1200
Frame Rate
50 Hz: 12.5 fps (1600 × 1200), 12.5 fps (1600 × 912), 25 fps (1280 × 960), 25
fps (1280 × 720)
60 Hz: 15 fps (1600 × 1200), 15 fps (1600 × 912), 25 fps (1280 × 960), 30 fps
(1280 × 720)
Image Setting
Saturation, Brightness, Contrast adjustable by client software or web
browser
Network
Network Storage
NAS (iSCSI optional)
Alarm Trigger
Motion detection, Video tampering, Network disconnect , IP address
conflict, Storage exception
Protocols
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP,
SNMP, FTP, 802.1x, QoS, HTTPS ( SIP,SRTP,IPv6 optional )
Security
User Authentication, Watermark
Standard
ONVIF, PSIA, CGI
Interface
Audio Input
1-ch 3.5 mm audio interface, MIC IN/Line IN
Audio Output
1-ch 3.5 mm audio interface (Line level, 600 Ω)
Communication
Interface
1 RJ45 10M/100M Ethernet port and 1 RS-485 interface
Alarm Input
2
Alarm Output
2
Video Output
1Vp-p composite output (75 Ω/RCA)
On-board
storage
Built-in SD/SDHC slot, up to 32 GB
Reset Button
Yes
General
