HIKVISION DS-2CD753F-E - Order Models

Hikvision Technical Manual
©2006 – 2012 by HIKVISION. All rights reserved.
5
Operating
Conditions
-10 °C – 60 °C (14 °F – 140 °F)
Humidity 90% or less (non-condensing)
Power Supply
12 V DC ± 10%
PoE (802.3af)
Power
Consumption
4.5W~9.5W
(IR: 2W,Motorized VF lens: 3W)
IR Range
-I: Approx. 10 to 20 meters
Impact
Protection
IEC60068-275Eh, 50J; EN50102, up to IK10
Dimensions
Φ 140 × 114 mm (Φ 5.51” × 4.49”)
Weight
1400 g (3.09 lbs)
* “-Z” is equipped with Motorized VF lens
Order Models
DS-2CD753F-E, DS-2CD753F-EI
DS-2CD753F-EZ, DS-2CD753F-EIZ
Dimensions
Unit: mm
Accessories
