HIKVISION ds-2cd8153f-e Quick Operation Guide

Quick Operation Guide of Network Camera
21
2
Lock Screw
Secure the sun shield
3
Cables
Power/Video Cable
1.4 Appearance Description of Cube Camera
1.4.1 Cube Camera I
Camera description:
Figure 1-33 Overview
Table 1-15 Description
No.
Description
1
Microphone
2
Infrared light (Optional)
3
Micro SD card slot
4
LINK: Network status LED indicator.
LED indicator is solid yellow when network connection is functioning
properly.
5
Power LED indicator, It is solid red when power is applied to the unit.
6
Lens
7
ETHERNET: 10M / 100M self-adaptive Ethernet interface
8
RESET: Reset button
9
Speaker
10
Power supply interface
11
Screw hole, used to fix the camera to the bracket
1
2
4
5
3
6
7
8
9
10
11
