HIKVISION DS-2CD883F-E series

Network Camera·Quick Operation Guide
7
7
Figure 1-2 Auto-iris Interface
Table 1-2 Pins
DC-driven
1
Damp-
2
Damp+
3
Drive+
4
Drive-
Power, Video and GND pins are used when the auto-iris is driven by
video; Damp+, Damp-, Drive+ and Drive- pins are used when the
auto-iris is driven by DC.
