HIKVISION DS-2CE12DF3T-PIRXOS User Manual

 EXTERNAL: The device outputs audible warning via
external speaker.
VOLUME: You can set the volume to HIGH, MEDIUM, or
LOW.
MOTION DET
MOTION DET refers to motion detection. With motion
detection feature, motion can be detected in any part
of a camera's view. You can configure full screen or a
number of zones in a camera’s view where motion is to
be detected.
PRIVACY
This function allows you to block or mask certain area
of a scene to protect personal privacy from being
recorded or live viewed. You can turn on/off the
PRIVACY to meet your needs.
3.7 FACTORY DEFAULT
Reset all the settings, except for image mode, to factory
defaults.
3.8 EXIT
Move the cursor to EXIT and click Iris+ to exit the menu.
3.9 SAVE & EXIT
Move the cursor to SAVE & EXIT and click Iris+ to save
the settings and exit the menu.
UD20405B

HIKVISION DS-2CE12DF3T-PIRXOS Specifications

General

Pan range	0 - 360 °
White balance	Auto, Manual
Tilt angle range	0 - 180 °
Angle of rotation	360 °
Camera shutter speed	1/25 - 1/50000 s
Minimum illumination	0.0005 lx
Fixed focal length	3.6 mm
Type	CCTV security camera
Day/night mode	Yes
Languages support	English
Number of languages	1
Placement supported	Outdoor
Connectivity technology	Wired
Built-in HDD	-
Form factor	Bullet
Mounting type	Ceiling/wall
Product color	White
Housing material	Metal, Plastic
International Protection (IP) code	IP67
DC output voltage	12
Power source type	DC
Power consumption (max)	11.4 W
Sensor type	CMOS
Operating temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	0 - 90 %
Night vision distance	40 m
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Image quality adjustment	Brightness, Contrast, Mirror, Sharpness
Noise reduction technology	3D noise reduction
Analog signal format system	NTSC, PAL
Supported graphics resolutions	1920 x 1080 (HD 1080)
Lens mount interface	M12

Weight and Dimensions

Width	82.6 mm
Height	77.1 mm
Length	213.2 mm
Weight	467 g
