HIKVISION DS-2CE56D0T-IRMMF

DC12VIN
Enclosure
Trim Ring
Mounting
Base
Main Body
Switch Button
Power Cord
Video Cable
Figure 1-4 Overview of Type II Camera (with F)
Note:
Press and hold the switch button for 5 seconds to
switch the video output. Four kinds of video outputs
are available: TVI, AHD, CVI, and CVBS.
1.2.3 Overview of Type III Camera
Enclosure
Main Body
Power Cord
Video Cable
Mounting
Base
Figure 1-5 Overview of Type III Camera (without F)
Note:
This camera is TVI only.
DC12VIN
Enclosure
Main Body
Switch Button
Power Cord
Video Cable
Mounting
Base
Figure 1-6 Overview of Type III Camera (with F)
Note:
Press and hold the switch button for 5 seconds to
switch the video output. Four kinds of video outputs
are available: TVI, AHD, CVI, and CVBS.
1.2.4 Overview of Type IV Camera
Mounting Base
Main Body
Enclosure
Switch Button
Power Cord
Video Cable
Figure 1-7 Overview of Type IV Camera
Note:
Press and hold the switch button for 5 seconds to
switch the video output. Four kinds of video outputs
are available: TVI, AHD, CVI, and CVBS.
