Explosion-proof IR Zoom Bullet Camera·Quick Start Guide
9
Note
There is no wall mounting bracket included in the package. You
have to prepare a wall mounting bracket if you choose this
mounting type. The shown bracket below is only for demonstration.
105.5
30
96
6.5
30 80
4-Ø 13
180
*290±0.1
332
*118± 0.1
309
562.5
Ø 13
Figure 2-2 Dimension of a Wall Mounting Bracket Type I (mm)
