HIKVISION DS-2DE4225IW-DE User Manual

© Hikvision
Notify surveillance center, send email, upload to FTP, trigger channel, smart tracking and
trigger alarm output are selectable. Refer to Section 5.2.1 Configuring Motion Detection.
11. Click button to save the settings.
5.3.7 Unattended Baggage Detection
Purpose:
Unattended baggage detection function detects baggage which is left in a pre-defined virtual
region, and some certain actions can be taken when the alarm is triggered.
Steps:
1. Enter the Unattended Baggage Detection settings interface:
Configuration> Event > Smart Event> Unattended Baggage Detection
2. Check the checkbox of Enable to enable the Unattended Baggage Detection function.
Figure 5-26 Configuring Region Exiting Detection
3. The event triggered and park action related PTZ movement will be locked for 180 seconds
after you enter the unattended baggage detection interface. Optionally, you can click the
button to manually activate the movement, or lock the movement
when the button turns to by clicking it.
4. Select the region from the dropdown list for detection settings.

HIKVISION DS-2DE4225IW-DE Specifications

General

Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Sensor type	CMOS
Optical sensor size	1/2.8 \
Digital zoom	16 x
Optical zoom	25 x
Focal length range	- mm
Maximum aperture number	3.8
Minimum aperture number	1.6
Pan range	0 - 360 °
Pan speed	80 °/sec
White balance	ATW, Auto, Fluorescent, Indoor, Manual, Outdoor, Sodium lamp
Tilt angle range	-15 - 90 °
Camera shutter speed	1/30000 - 1 s
Minimum illumination	0 lx
Preset programs quantity	300
Total megapixels	2 MP
Gain control type	Auto/Manual
Maximum resolution	1920 x 1080 pixels
Video compression formats	H.264, H.264+, H.265, H.265+, M-JPEG
Supported graphics resolutions	352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080)
LED type	IR
Night vision distance	100 m
Number of cameras	1
DC output voltage	12
Power source type	DC, PoE
Power consumption (Power over Ethernet (PoE))	18 W
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	256 GB
Behavior analysis	Intrusion detection, Line crossing detection, Object removal detection, Unattended baggage detection
Security algorithms	802.1x RADIUS
Intelligent Video Surveillance (IVS) system features	Face detection
Bluetooth	-
Number of users	32 user(s)
Networking standards	IEEE 802.3at
Supported network protocols	IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
Operating temperature (T-T)	-30 - 65 °C
Form factor	Dome
Mounting type	Ceiling/wall
Product color	White
International Protection (IP) code	IP66

Weight and Dimensions

Height	290 mm
Weight	2000 g
Diameter	164.5 mm
