HIKVISION DS-2DE4225IW-DE User Manual

© Hikvision
Figure 5-35 Clear Config
3. Click to clear the settings.
5.4.8 Configuring Smart Tracking
Purpose:
The speed dome tracks the moving objects automatically after you configure this function.
Note:
The VCA speed dome do not support this function.
Steps:
1. Enter the Smart Tracking settings interface:
Configuration > PTZ > Smart Tracking
Figure 5-36 Configure Smart Tracking
2. Check the Enable Smart Tracking check box to enable smart tracking function.
3. Set zoom ratio for tracking. You can set a fixed zoom ratio. Or you can let the camera
calculates the actual zoom ratio automatically.
• Set a Fixed Zoom Ratio
1. Move the Tracking Zoom Ratio cursor to 0.
2. Select a target in the live image and adjust the PTZ buttons to see the target at
desired size.

HIKVISION DS-2DE4225IW-DE Specifications

General

Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Sensor type	CMOS
Optical sensor size	1/2.8 \
Digital zoom	16 x
Optical zoom	25 x
Focal length range	- mm
Maximum aperture number	3.8
Minimum aperture number	1.6
Pan range	0 - 360 °
Pan speed	80 °/sec
White balance	ATW, Auto, Fluorescent, Indoor, Manual, Outdoor, Sodium lamp
Tilt angle range	-15 - 90 °
Camera shutter speed	1/30000 - 1 s
Minimum illumination	0 lx
Preset programs quantity	300
Total megapixels	2 MP
Gain control type	Auto/Manual
Maximum resolution	1920 x 1080 pixels
Video compression formats	H.264, H.264+, H.265, H.265+, M-JPEG
Supported graphics resolutions	352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080)
LED type	IR
Night vision distance	100 m
Number of cameras	1
DC output voltage	12
Power source type	DC, PoE
Power consumption (Power over Ethernet (PoE))	18 W
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	256 GB
Behavior analysis	Intrusion detection, Line crossing detection, Object removal detection, Unattended baggage detection
Security algorithms	802.1x RADIUS
Intelligent Video Surveillance (IVS) system features	Face detection
Bluetooth	-
Number of users	32 user(s)
Networking standards	IEEE 802.3at
Supported network protocols	IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
Operating temperature (T-T)	-30 - 65 °C
Form factor	Dome
Mounting type	Ceiling/wall
Product color	White
International Protection (IP) code	IP66

Weight and Dimensions

Height	290 mm
Weight	2000 g
Diameter	164.5 mm
