Digital Video Recorder User Manual
46
4. Select a recording type.
Continuous
Scheduled recording.
Event
Recording triggered by all event triggered alarm.
Motion
Recording triggered by motion detection.
Alarm
Recording triggered by alarm.
M/A
Recording triggered by either motion detection or alarm.
M&A
Recording triggered by motion detection and alarm.
POS
Recording triggered by POS and alarm.
5. Drag the cursor on time bar to set the record schedule.
Figure 4-2 Record Schedule

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7100HGHI-M1 Series and is the answer not in the manual?

HIKVISION DS-7100HGHI-M1 Series Specifications

General IconGeneral
Audio Bitrate64 Kbps
Video Input4/8/16
AHD InputYes
CVBS InputYes
IP Video InputYes
HDMI Output1
VGA Output1
Audio Output1
Two-Way AudioYes
Recording Resolution1080p/720p
Encoding Resolution1080p/720p
Frame Rate25/30fps
Dual StreamYes
Stream TypeVideo/Audio
CompressionH.264+/H.264
Network ProtocolsTCP/IP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, SMTP, NTP, UPnP, SNMP, 802.1X, QoS, IPv6, Bonjour
Network Interface1, RJ45 10/100 Mbps self-adaptive Ethernet interface
SATA1
Hard Drive CapacityUp to 6 TB capacity for each disk
USB Interface2 (USB 2.0)
Power Consumption≤ 8 W
Working Temperature-10°C ~ +55°C
Working Humidity10% ~ 90%
