Digital Video Recorder User Manual
50
safety and reliability.
Before You Start
You must set the storage mode to Group before you set the HDD property to Redundancy. For
detailed information, refer to Configure HDD Group. There should be at least another HDD which
is in Read/Write status.
Steps
1. Go to Storage Storage Device.
2. Select a HDD from the list and click to enter the Local HDD Settings interface.
3. Set the HDD property to Redundancy.
4. Go to Storage Schedule Settings Record Schedule/Capture Schedule.
5. Click Advanced to set the camera recording parameters.
Figure 4-4 Record Parameters
6. Check Redundant Record/Capture.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7100HGHI-M1 Series and is the answer not in the manual?

HIKVISION DS-7100HGHI-M1 Series Specifications

General IconGeneral
Audio Bitrate64 Kbps
Video Input4/8/16
AHD InputYes
CVBS InputYes
IP Video InputYes
HDMI Output1
VGA Output1
Audio Output1
Two-Way AudioYes
Recording Resolution1080p/720p
Encoding Resolution1080p/720p
Frame Rate25/30fps
Dual StreamYes
Stream TypeVideo/Audio
CompressionH.264+/H.264
Network ProtocolsTCP/IP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, SMTP, NTP, UPnP, SNMP, 802.1X, QoS, IPv6, Bonjour
Network Interface1, RJ45 10/100 Mbps self-adaptive Ethernet interface
SATA1
Hard Drive CapacityUp to 6 TB capacity for each disk
USB Interface2 (USB 2.0)
Power Consumption≤ 8 W
Working Temperature-10°C ~ +55°C
Working Humidity10% ~ 90%
