Steps

Go to Conguraon → Network → General → TCP/IP .

Congure network parameters.

Working Mode

Mul-address Mode

The parameters of the two NIC cards can be congured independently. You can select

LAN1 or LAN2 in the NIC type

eld for parameter sengs. You can select one NIC card as

default route. And then the system is connecng with the extranet and the data will be

forwarded through the default route.

Net-fault Tolerance Mode

The two NIC cards use the same IP address, and you can select the Main NIC to LAN1 or

LAN2. By this way, in case of one NIC card failure, the video recorder will

automacally

enable the other standby NIC card so as to ensure the normal running of the whole

system.

Load Balance Mode

By using the same IP address and two NIC cards share the load of the total bandwidth,

which enables the system to provide two Gigabit network capacity.

Note

Working mode is only available for certain models.

NIC Type

Select NIC type as your desire. If your device supports Wi-Fi dongle funcon, the NIC of Wi-Fi

dongle would be selectable

aer a suitable Wi-Fi dongle is installed.

DHCP

If the DHCP server is available, you can check Enable DHCP to automacally obtain an IP

address and other network sengs from that server.

MTU

The maximum transmission unit (MTU) is the size of the largest network layer protocol data

unit that can be communicated in a single network

transacon.

Default Route

Select a route as your desire. If your device supports Wi-Fi dongle funcon, the route of Wi-Fi

dongle would be selectable

aer a suitable Wi-Fi dongle is installed.

Auto Obtain DNS

If DHCP is checked. You can check Obtain DNS Automacally to obtain Preferred DNS Server

and Alternate DNS Server.

Click Apply.
