Table 10 Specifications for DS-7300HWI-SH
Model
DS-7304HWI-SH
DS-7308HWI-SH
DS-7316HWI-SH
Video/Audio
input
Video compression
H.264
Video input
4-ch
8-ch
16-ch
Video input interface
BNC (1.0 Vp-p, 75 Ω), PAL /NTSC self-adaptive
Audio compression
G.711u
Audio input
4-ch, RCA (2.0 Vp-p, 1 kΩ)
Two-way audio input
1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
Video/Audio
output
HDMI/VGA output
1-ch, resolution:
1080P: 1920×1080/60Hz,
SXGA: 1280×1024/60Hz,
720P: 1280×720/60Hz,
XGA: 1024×768/60Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Video spot out
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Encoding resolution
WD1/4CIF / 2CIF / CIF / QCIF
Frame rate
25 fps (P) / 30 fps (N)
Video bit rate
32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps)
Audio output
2-ch, RCA (Linear, 600 Ω)
Audio bit rate
64 Kbps
Dual-stream
Support; Sub-stream: CIF / QCIF @ 25 fps (P) / 30 fps (N))
Stream type
Video, Video &
Audio
Channel1-4: Video,
Video & Audio
Channel5-8: Video
Channel1-4:
Video, Video & Audio
Channel5-16: Video
Synchronous
playback
4-ch
8-ch
16-ch
Hard disk
SATA
4 SATA interfaces
eSATA
1 eSATA interface
Capacity
Up to 4TB capacity
External
interface
Network interface
1, RJ45 10M / 100M / 1000M Ethernet interface
Serial interface
1 RS-232, RS-485(half-duplex), Keyboard
USB interface
3 × USB 2.0
Alarm in
4
8
16
Alarm out
1
4
4
General
Power supply
100~240VAC, 5A, 50~60Hz
Consumption
(without HDD or
DVD-R/W)
≤ 25 W
≤ 30 W
≤ 35 W
Working
temperature
-10 ºC ~+55 ºC
Working humidity
10% ~ 90%
Chassis
19-inch rack-mounted 1.5U chassis
Dimensions
(W × D × H)
445 × 390 × 70 mm
Weight
(without HDD or
DVD-R/W)
≤ 5 kg
