HIKVISION DS-7204HVI-SH series - Rear Panel

Quick Operation Guide of DS-7200-SH/SV&DS-7300-SH Series DVR
5
Rear Panel
DS-7204HVI/HFI/HWI-SH and DS-7204HVI-SV:
DS-7216HVI-SH and DS-7216HVI-SV:
1 2
3 4 5
6
7 8 9 10
11
12
Note: The rear panels of DS-7208HVI-SH and DS-7208HVI-SV provide 8 video input interfaces.
DS-7216HFI-SH and DS-7216HWI-SH:
3 4 5 7 8 9 10
11
1 2 6
12
Note: The rear panels of DS-7208HFI-SH and DS-7208HWI-SH provide 8 video input interfaces.
Table 3 Description of Rear Panel
No.
Item
Description
1
VIDEO IN
BNC connector for analog video input.
2
VIDEO OUT
BNC connector for video output.
3
USB Interface
Connects USB mouse or USB flash memory devices.
4
HDMI
HDMI video output.
5
VGA
DB15 connector for VGA output. Display local video output and menu.
6
AUDIO IN
RCA connector for audio input.
7
AUDIO OUT
RCA connector for audio output.
8
LAN Interface
RJ45 10M / 100M Ethernet interface.
9
RS-485 Interface
Connector for RS-485 devices. Connect the D+ and D- terminals to R+
and R- terminals of PTZ receiver respectively.
10
12V
12VDC power supply.
11
POWER
Switch for turning on/off the device.
12
GND
Ground(needs to be connected when DVR starts up)
