DS-72xxHUI-Kx, DS-72xxHQI-Kx Digital Video Recorder (DVR) User Manual
UM DS-72xxHUI-Kx, DS-72xxHQI-Kx 062817NA 105
Chapter 8 Alarm Settings
8.1 Setting Motion Detection
1. Enter Motion Detection interface of Camera Management, Menu > Recording Configuration > Motion
Detect.
2. Choose a camera for which you want to set up motion detection,
Figure 135, Motion Detection Setup Interface
3. Set detection area and sensitivity.
4. Check the motion detection checkbox to enable it.
5. Use the mouse to draw detection area(s) or click Full Screen to set the detection area to be the full screen.
6. Drag the sensitivity bar to set sensitivity.
7. Click to set alarm response actions.
