DS-72xxHUI-Kx, DS-72xxHQI-Kx Digital Video Recorder (DVR) User Manual
UM DS-72xxHUI-Kx, DS-72xxHQI-Kx 062817NA 37
• For DS-72xxHUI-Kx Series DVRs with CVBS Output: The VGA/HDMI output is the main output, and the
CVBS output is the aux output. The priority relationship is shown as Table 3-2.
Table 1-2 Priorities of Outputs for DS-72xxHUI-Kx Series
S.N HDMI VGA CVBS Main output Auxiliary output
1 √ or × √ or × √ or × VGA/HDMI CVBS
√ means the interface is in use, × means the interface is out of use
or the connection is invalid. The HDMI, VGA, and CVBS can be used
at the same time.
When present the HDMI/VGA will provide the main monitor output
with the CVBS serving only as a spot (Live View) monitor. If no HDMI
or VGA monitor is connected at the time of bootup, the CVBS
monitor can be used as the main monitor, allowing control of menu
and playback. A reboot is required to return this function to the
HDMI/VGA monitor(s).
3.2.1 Using the Mouse in Live View
Table 1-3 Mouse Operation in Live View
Name Description
Menu
Enter the main menu of the system by right clicking the mouse.
Single Screen
Switch to the single full screen by choosing channel number fr
om the
drop
-
down
list.
Multi
-
S
creen
Adjust the screen layout by
select
ing from the
drop
-
down
list.
Previous Screen
Switch to the previous screen.
Next Screen
Switch to the next screen.
Start/Stop
Auto-Switch
Enable/disable the auto
-
switch of the scree
ns.
Set t
he
Live V
iew configuration
dwell time
before using
Start Auto
-
S
witch
.
Start Recording
Start recording of all channels,
Continuous
Recor
d and Motion
Detection Record
are selectable from the
drop
-
down
list.
Add IP Camera
A shortcut to enter the
IP camera management interface.
(For HDVR
series only)
Playback
Enter the playback interface and start playing back the video of the
selected channel immediately.
PTZ Control
A shortcut to enter the PTZ control interface of the selected camera.
Output M
ode
Output Mode is configurable with Standard, Bright, Gentle and Vivid
options.
