Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR
7
In the PTZ Control mode, it is used to adjust the iris of the PTZ camera.
The DIRECTION buttons are used to navigate between different fields
and items in menus.
In the Playback mode, the Up and Down button is used to speed up and
slow down recorded video. The Left and Right button will select the next
and previous record files .
In Live View mode, these buttons can be used to cycle through channels.
In PTZ control mode, it can control the movement of the PTZ camera.
The ENTER button is used to confirm selection in any of the menu
modes.
It can also be used to tick checkbox fields.
In Playback mode, it can be used to play or pause the video.
In single-frame Playback mode, pressing the button will advance the
video by a single frame.
In Auto-switch mode, it can be used to stop /start auto switch.
Move the active selection in a menu. It will move the selection up and
down.
In Live View mode, it can be used to cycle through different channels.
In the Playback mode: For DS-9100/9000HFI-ST series, the ring is used
to jump 30s forward/backward in video files. For DS-8100/8000HFI-ST
series, the outer ring is used to speed up or slow down the record files
and the inner ring is used to jump 30s forward/backward in records files.
In PTZ control mode, it can control the movement of the PTZ camera.
Connects USB mouse or USE flash memory devices.
POWER: the POWER indicator turns green when NVR is
powered up.
READY: The indicator light is green when the device is
running normally.
STATUS: 1.The light is green when the IR remote control is
enabled; 2.The light is red when the function of the composite
keys (SHIFT) are used; 3. The light is out when none of the
above condition is met/
ALARM: the light is red when there is an alarm occurring.
HDD: the indicator flickers red when HDD is reading/writing.
