S E T U P R E C O R D I N G ( c o n t i n u e d )
- Video Quality adjusts picture clarity (high setting = four green squares is default).
Consider highest if hard drive space allows.
- Frame Rate sets recording frame rate (8 fps on continuous and 15 fps on motion by
default). Higher frame rates require more storage, but allows better slow motion
playback.
- Max Bitrate Mode chooses between pre-set bitrate values and customized values
(General setting is default).
- Max Bitrate (KBPS) is the chosen bitrate for streaming the video. Max Bitrate should
be adjusted to meet or exceed the rate recommended by the system for the chosen
parameters.
- Max Bitrate Recommended is impacted by resolution, quality, and framerate.
- Record Audio turns on audio recording. Requires connection of external microphone or
camera with built in mic.
- Video Stream determines which stream is recorded. Leave at default (Main Stream).
• Substream
1. Go to RECORDING CONFIGURATION > RECORD QUALITY > SUBSTREAM to set up
the Sub Stream to stream to mobile devices and display multiple cameras locally.
NOTE: If the upload speed is not sufficient, lower the frame rate, bitrate,
and or resolution for more fluent mobile viewing.
q
qq
q
Select tab
w
ww
w CAMERA
Select camera
e
ee
e EVENT
For event recording only (motion
or alarm)
r
rr
r
CONTINUOUS
For live view image and
continuous recording
t
tt
t
VIDEO QUALITY
Select
number of green squares
to set quality (in example,
sensitivity is set to 4)
w
