Digital Video Recorder User Manual
251
Figure 16-8 FTP Upgrade Interface
Step 3 Enter the FTP Server Address in the text field.
Step 4 Click the Upgrade button to start upgrading.
Step 5 After the upgrading is completed, reboot the DVR to activate the new firmware.
16.6 Upgrading Camera
Purpose
You can upgrade multiple connected analog cameras supporting Turbo HD or AHD signal
simultaneously with DVR.
This chapter is applicable to the DS-7200HUHI-F/S series DVR.
Step 1 Enter the Camera Upgrade interface.
Figure 16-9 Camera Upgrade
Step 2 Check the checkbox(es) of the analog camera(s) for upgrading.
The analog camera must support Turbo HD or AHD signal.
Step 3 Select the update file from the backup device.
Step 4 Click the Upgrade button to start upgrading.
16.7 Restoring Default Settings
Step 1 Enter the Default interface.
Menu > Maintenance > Default

Table of Contents

Other manuals for HIKVISION DS-8116HQHI-F8/N

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-8116HQHI-F8/N and is the answer not in the manual?

HIKVISION DS-8116HQHI-F8/N Specifications

General IconGeneral
Video CompressionH.265+/H.265/H.264+/H.264
Two-Way AudioYes
Video Bitrate32Kbps to 10Mbps
Audio Bitrate64Kbps
Dual StreamYes
Synchronous Playback16-ch
Remote Connections128
USB Interface2 USB 2.0
Alarm In/Out16/4
Working Humidity10% to 90%
Dimensions445 mm × 400 mm × 71 mm (17.5 inch × 15.7 inch × 2.8 inch)
Weight≤6.5kg (14.33lb)
Video Input16 channels
AHD Input16 channels
HDCVI Input16 channels
CVBS Input16 channels
IP Video Input16 channels
Audio CompressionG.711u
Audio Input16 channels
Video OutputHDMI, VGA, CVBS
HDMI Output1
VGA Output1
CVBS Output1
Recording Resolution1080p/720p/WD1/4CIF/VGA/CIF
Audio Output1
Stream TypeVideo, Video & Audio
Network ProtocolsTCP/IP, DHCP, DNS, DDNS, HTTP, P2P
SATA8
CapacityUp to 10TB per HDD
Network Interface1 RJ45 10M/100M/1000Mbps
Serial Interface1 RS-485
Power Supply100-240V AC, 50/60Hz
Consumption≤40W (without HDD)
Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
HDD CapacityUp to 10 TB capacity for each HDD
Playback Resolution1080p/720p/WD1/4CIF/VGA/CIF
Power Consumption≤40W (without HDD)
