HIKVISION DS-C30S-L104 Quick Start Guide

Video Wall Controller • Quick Start Guide
5
No.
Name
Description
1
Power LED
When the board is powered on normally, the power
LED is steady green.
2
Active LED
When the board runs normally, the active LED is
flashing green.
3
VGA video input port
Provide 4 ports for VGA video input.
4
Audio input port
Provide a mini-DP 4-in-1 line-in audio input port.
Use an external audio adapter cable to connect to
this port for audio input.
HDMI UHD Input Board
1
2
3
Front View of HDMI UHD Input Board
No.
Name
Description
1
Power LED
When the board is powered on normally, the
power LED is steady green.
2
Active LED
When the board runs normally, the active LED is
flashing green.
3
HDMI video input port
Provide 2 ports for HDMI UHD video input.

HIKVISION DS-C30S-L104 Specifications

General

Brand	HIKVISION
Model	DS-C30S-L104
Category	Controller
Language	English
