HIKVISION DS-K1104M User Manual

DS-K1100 Series Card Reader
10
Yellow
Blue
Black
Red
Black
Red
Green
White
Purple
Orange
Brown
Controller
Card Reader
Figure 2-4 Wiring for RS-485 Communication Mode
Steps for Wiegand communication mode:
1. Set the DIP switch of No. 6 as 1.
2. Set the DIP switch of No. 5 and 7 for reading card mode and
Wiegand protocol. For details, please refer to 2.2
Introduction for DIP Switch.
3. Wiring the cable between controller and card reader as
shown below.

HIKVISION DS-K1104M Specifications

General

Brand	HIKVISION
Model	DS-K1104M
Category	Card Reader
Language	English
