Figure 3-2 Dimension
1. Prepare for the installaon tools, check the components, and prepare for the installaon base.
2. Drill holes on the ground according to the installaon holes on the pedestals and insert the
expansion sleeves.
3. According to the entrance and exit marks on the pedestals, move the pedestals to the
corresponded
posions.
Note
Make sure the installaon holes on the pedestals and the base are aligned with each other.
4. Secure the pedestals with expansion bolts.
Note
• The suggested expansion bolt's size is M12*150. You can change or transform the expansion
bolt according to your actual needs. But make sure that do not drill through the oor. If the
oor is too so to install, it is suggested to apply the construcon adhesive to strengthen.
• Do not immerse the pedestal in the water. In special circumstances, the immersed height
should be no more than 150 mm.
• The
installaon footprint is as follows:
