HIKVISION DS-K3Y411 Series User Manual

Chapter 4 General Wiring
Note
•
Aer maintenance, you should close the water-proof cover over the high/low voltage module.
• When you should maintain or disassemble the high voltage modules, you should remove the
enre high voltage modules and maintain it outside the turnsle. You should unplug the cables
that connected to the peripherals before maintenance to avoid destroy of the device.
4.1 Components Introducon
By default, basic components of the turnsle are connected well. The pedestals can communicate
by wiring the
interconnecng cables. And the turnsle supports wiring the AC electric supply for
the whole system's power supply.
Note
The voltage uctuaon of the electric supply is between 100 VAC and 240 VAC, 50 to 60 Hz.
The picture displayed below describes each component's posion on the turnsle.
Note
The diagram is for reference only.
Figure 4-1 Components Diagram 1
DS-K3Y411X Series Flap Barrier Quick Start Guide
10
