HIKVISION DS-K3Y411 Series - 4.4 Face Recognition Terminal Power Supply Wiring (Optional)

Note
The right/middle pedestal contains an interconnecng cable, including one network cable (3.75 m)
and one 2-core cable.
The picture displayed below describes the cable hole's posion on the pedestals.
Figure 4-3 Cable Hole of Interconnecng Cable
Follow the instrucons below to connect the interconnecng cable.
Figure 4-4 Connect Interconnecng Cable
DS-K3Y411X Series Flap Barrier Quick Start Guide
13
