Figure 4-7 UART No. Descripon
Table 4-1 UART Related
Posion/Terminals/DIP Switch Introducon
UART No. Related Terminals Terminal Posion DIP Switch No. Funcon
UART1
Note
External card
reader is
recommended to
access.
485A/232A BUS of Main Lane
Control Board
1 to 3 ON: UART1 is RS-
232A Interface
4 to 6 ON: UART1 is RS-
485A Interface
7 Reserved
8 Reserved
UART3 485C+/232C+ Access Control
Board
1 to 3 ON: UART3 is RS-
232C Interface
DS-K3Y411X Series Flap Barrier Quick Start Guide
16
