HIKVISION DS-K3Y411 Series - BUS Terminal Details for Sub Lane Controllers

Terminal Name Descripon
UART 1
Note
External card reader is
recommended to access.
Red 12 V: connects 12 VDC power supply terminal
Yellow 485A/232A+: card reader RS-485A+/RS-232A+ access
terminal
Blue 485A/232A-: card reader RS-485A-/RS-232A- access
terminal
Black GND: grounding
Table 4-3 BUS Terminal in Sub Lane Controller (Le Pedestal)
Terminal Name Descripon
Lane Controller Light Board 1 Connects lane controller light board 1
Lane Controller Light Board 2 Connects lane controller light board 2
Fan Connects fan
TAMPER1 Connects TAMPER1
TAMPER2 Connects TAMPER2
Lane Controller Board Connect sub lane controller board
5 V Reserved
IR Adaptor Connects IR adaptor
UART 5
Note
External card reader is
recommended to access.
Red 12 V: connects 12 VDC power supply terminal
Yellow 485E/232E+: card reader RS-485E+/RS-232E+ access
terminal
Blue 485E/232E-: card reader RS-485E-/RS-232E- access terminal
Black GND: grounding
UART 6
Note
External face recognion
terminal is recommended to
access.
Red 12 V: connects 12 VDC power supply terminal
Yellow 485F/232F+: card reader RS-485F+/RS-232F+ access
terminal
Blue 485F/232F-: card reader RS-485F-/RS-232F- access terminal
Black GND: grounding
Table 4-4 BUS Terminal in Sub Lane Controller (Middle Pedestal)
Terminal Name Descripon
Lane Controller Light Board 1 Connects lane controller light board 1
Lane Controller Light Board 2 Connects lane controller light board 2
