Figure 3-2 Dimension
1. Prepare for the installaon tools, check the components, and prepare for the installaon base.
2. Drill holes on the ground according to the installaon holes on the pedestals and insert the
expansion sleeves.
3. According to the entrance and exit marks on the pedestals, move the pedestals to the
corresponded
posions.
Note
Make sure the installaon holes on the pedestals and the base are aligned with each other.
4. Secure the pedestals with expansion bolts.
Note
• The suggested expansion bolt's size is M12*150. You can change or transform the expansion
bolt according to your actual needs. But make sure that do not drill through the oor. If the
oor is too so to install, it is suggested to apply the construcon adhesive to strengthen.
• Do not immerse the pedestal in the water. In special circumstances, the immersed height
should be no more than 150 mm.
• The
installaon footprint is as follows:
DS-K3Y411X Series Flap Barrier Quick Start Guide
8
