Access Control Board Terminal Descripon
through the
embedded
pipe and
connects
with the QR
code on the
le.
Power Input +24 V 24 VDC Power Input /
GND Grounding
Event Input C1 Event Alarm Input 1 The event
alarm input
hardware
interface is
remaining
open, and only
supports access
to remaining
open signals,
which can be
linked to the
host buzzer
output, card
reader buzzer
output, alarm
relay output,
door open relay
output, etc.
G Grounding
C2 Event Alarm Input 2
Exit Buon B2 Door 2 Signal Input /
G Grounding
B1 Door 1 Signal Input
Door Lock (Relay) D1- Door 1 Relay Output (Dry Contact) If necessary,
the door lock
relay can be
used to control
the third-party
barrier switch.
D1 controls the
door opening
D1+
