HIKVISION DS-KH6310-W Quick Start Guide

Video Intercom Indoor Station·Quick Start Guide
26
Adding Device (Indoor Extension)
Indoor extension can only connect to the indoor station.
Steps:
1. Get to the configuration interface: Settings > Configuration, and enter the admin
password (configuration password).
2. Press the Device tab to enter the device management interface.
3. Press the Indoor Station tab to pop up the device information dialogue box.
Figure 5-13 Indoor Station Adding Interface (Indoor Extension)
4. Enter the IP address of the indoor station, and press the tab to save the settings.
5.4 Calling Resident
Steps:
1. Press the tab on the touch screen to enter the residents calling
interface.
2. Enter the corresponding resident’s Room No..
3. Press the tab to start an audiovisual call.
4. Press the tab to stop the audiovisual call.
 Generally speaking, Room No. format should be like 1-2-3-405 as Community 1,
Building 2, Unit 3, and Room 405. The community No. can be omitted.
 Switch to on the upper right corner to enable the camera function.
 The Room No. can be automatically saved into the contact list.

HIKVISION DS-KH6310-W Specifications

General

Color	Yes
Certification	FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
Number of buttons	4 buttons
Connectivity technology	Wired
Sustainability certificates	RoHS
Voice codecs	G.711u
Display diagonal	7 \
Display resolution	800 x 480 pixels
Display technology	LCD/TFT
Indoor unit power type	AC/DC
Power consumption (typical)	10 W
Operating relative humidity (H-H)	10 - 90 %
Main monitor station operating temperature (T-T)	-10 - 55 °C
Proper use	Indoor
Control type	Buttons, Touch
Product color	White
Operating system installed	Linux
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, RTSP

Weight and Dimensions

Depth	26 mm
Width	217 mm
Height	142 mm
