Note
If the door staon is inacve, the system will pop up the dialog to acvate the door staon.
2) Edit the network parameters of the door staon manually.
3) Tap Next.
9.
Oponal: Enable Indoor Staon and link related indoor extension devices. Tap Finish. If the
indoor extension and the indoor staon are in the same LAN, the device will be displayed in the
list. Tap the device or enter the serial No. to link.
Figure 3-16 Related Device
1) Tap the door staon in the list to link.
Note
If the indoor extension is inacve, the system will pop up the dialog to acvate the device.
2) Edit the network parameters of the indoor extension manually.
10.
Tap Finish to save the sengs.
3.3 Basic
Sengs
Basic sengs is required before starng using the indoor staon. It is necessary to set the indoor
staon network, room No., linked devices, device me display, and so on.
Network Indoor Staon Conguraon Guide
15

HIKVISION DS-KH8350-WTE1 Specifications

General

Product color	Black
Package weight	899 g
Indoor unit included	Yes
Outdoor unit included	No
Display diagonal	7 \
Display resolution	1024 x 600 pixels
Operating system installed	Linux
Voice codecs	G.711u
Number of speakers	1
Certification	FCC, IC, CE, C-TICK, ROHS, REACH, WEEE, UL, CB, RCM
Connectivity technology	Wired & Wireless
Maximum number of cameras supported	-
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, SIP, RTSP
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Power consumption	200 mA
Indoor unit power type	DC
Power consumption (typical)	7 W
Operating relative humidity (H-H)	10 - 90 %
Main monitor station operating temperature (T-T)	-10 - 55 °C

Weight and Dimensions

Weight	355 g
Door station dimensions (WxDxH)	180 x 140 x 22.4 mm
