HIKVISION HWD-7100MH Series User Manual

Digital Video Recorder User Manual
121
Figure 8-11 Disarm Linkage Actions
When the alarm input 1 (Local<-1) is enabled with one-key disarming, the other alarm input
settings are not configurable.
8.4 Detecting Video Loss
Purpose
Detect video loss of a channel and take alarm response action(s).
Step 1 Go to Menu > Camera > Video Loss.
Figure 8-12 Video Loss Setup Interface
Step 2 Select a Camera you want to detect.
Step 3 Set up handling method of video loss.
Check the checkbox of Enable Video Loss Alarm.

HIKVISION HWD-7100MH Series Specifications

General

Working Humidity	10% to 90%
Video Input	4/8/16
CVBS Input	Yes
Audio Output	1
Video Compression	H.264+/H.264
Audio Compression	G.711
SATA	1 SATA interface
Network Interface	1, RJ45 10M/100M self-adaptive Ethernet interface
USB Interface	2 USB 2.0
Working Temperature	-10°C to +55°C
