iDS-2CD7046G0-AP Network Box Camera Quick Start Guide
QSG iDS-2CD7046G0-AP 022321NA 8
NOTE: Power indicator: red stands for starting and blue for working.
To reset the camera default parameters, press and hold the RESET button and power on the
camera. After the camera powers on, continue to press and hold the Reset button for 10
seconds.
ABF is supported by certain camera models.
2 Installation
Before You Start
•
Make sure the device in the package is in good condition and all the assembly parts are included.
•
The standard power supply is 12 VDC, 24 VAC, or PoE. Make sure power supply matches camera.
•
Make sure all related equipment is powered off during the installation.
•
Check the product specifications for the installation environment.
•
Make sure that the wall can withstand four times the weight of the camera and the bracket.
For cameras that support IR, you must pay attention to the following precautions to prevent IR reflection:
•
Make sure that there is no reflective surface too close to the camera lens. The IR light from the camera
may reflect back into the lens causing reflection.
2.1
Memory Card Installation
Only certain camera models support memory card installation. The actual device appearance may vary by
model. The following takes a model as an example to illustrate the installation steps.
Steps
1. Insert the memory card to the memory card slot on the camera’s rear panel.
2. (Optional) To unmount the memory card, push it in to eject it.
Figure 2, Memory Card Installation
