iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual
UM iDS-2CD7xxG0-xxxxx 021021NA 29
OSD
You can customize OSD (On-screen Display) information such as device name, time/date, font, color, and
text overlay displayed on video stream.
Go to OSD setting page: Configuration → Image → OSD Settings. Set the corresponding parameters, and
click Save to take effect.
• Character Set: Select character set for displayed information. If Korean is required to displayed on
screen, select EUC-KR. Otherwise, select GBK.
• Displayed Information: Set camera name, date, week, and their related display format.
• Text Overlay: Set customized overlay text on image.
• OSD Parameters: Set OSD parameters, such as Display Mode, OSD Size, Font Color, and Alignment.
Set Privacy Mask
The function blocks certain areas in the live view to protect privacy. No matter how the device moves, the
blocked scene will never be seen.
Steps
1. Go to privacy mask setting page: Configuration → Image → Privacy Mask.
2. Check Enable Privacy Mask.
3. Click Draw Area. Drag the mouse in the live view to draw a closed area.
• Drag the Corners of the Area: Adjust the size of the area.
• Drag the Area: Adjust the position of the area.
• Click Clear All: Clear all the areas you set.
4. Click Stop Drawing.
5. Click Save.
Up to four areas are supported for setting.
Overlay Picture
Overlay a customized picture on live view.
Before You Start
The overlay picture has to be in 24-bit BMP format, and the maximum picture size is 128 x 128 pixels.
