Network Video Recorder Quick Start Guide
40
Figure 3-8 Live View
You can use the toolbar at the window bottom to realize the capture, instant playback, audio
on/off, digital zoom, live view strategy, show information and start/stop recording, etc.
3.9 One-Touch RAID Configuration
Purpose:
The device supports the RAID storage function. Through one-touch configuration, you can quickly
create the disk array. By default, the array type to be created is RAID 5.
Before you start:
Enable RAID function.
Install at least 3 HDDs. If more than 10 HDDs are installed, 2 arrays will be created. To maintain
reliable and stable running of the HDDs, it is recommended to use enterprise-level HDDs with
the same model and capacity.
Step 1 Go to Storage > RAID Setup > Physical Disk.
Figure 3-9 Physical Disk
Step 2 Click One-touch Config.
