8.0 Appendix 1
Installation Notice
While installing the doorbell, make sure that the distance between any two devices is far enough to
avoid howling and echo. The distance between two devices is recommended to be longer than 10
meters.
Devices mentioned here refer to indoor station, door station, and master
station.
Wiring Cables
Cable
Specification
Power Cord of Doorbell
RVV 2*1.0
Network Cable of Doorbell
UTP-five Categories
Door Lock Wiring (with Door Contact)
RVV 4*1.0
Door Lock Wiring (without Door Contact)
RVV 2*1.0
Exit Button Wiring
RVV 2*0.5
