KB88113 Vandal-Resistant Video Intercom Doorbell User Manual
UM KB8113 Doorbell 021821NA 32
Figure 7-18 Elevator Control
Check to enable elevator control function.
Select an Elevator No., and select an elevator controller type for the elevator.
Set the Negative Floor.
Set the Interface Type as RS-485 or Network Interface and enable the elevator control.
• If you select RS-485, make sure you have connected the door station to the elevator
controller with an RS-485 cable.
• If you select Network Interface, enter the elevator controller’s IP address, port no., user
name, and password.
Click Save to enable the settings.
Up to four elevator controllers can be connected to one door station.
Up to 10 negative floors can be added.
Make sure the elevator controller interface types connected to the same door
station are consistent.
7.5 Number Settings
Link the room no. and SIP numbers. Click Number Settings to enter the page.
Click Add, set the Room No. and SIP numbers in the pop-up dialog box.
7.6 Device Management
You can manage the linked device on the page. Click Device List to enter the settings page.
