KB88113 Vandal-Resistant Video Intercom Doorbell User Manual
UM KB8113 Doorbell 021821NA 5
3.0 Doorbell Installation
3.1 Wall Mounting Plate
Figure 3-1 Wall Mounting Plate
To install the doorbell onto the wall, you are required to use a matched mounting plate.
3.2 Wall Mounting
Fix the wall mounting plate to the wall with four expansion screws.
NOTE: Recommended Installation height is 47" to 55".
Figure 3-2 Install the Plate
