HIKVISION MV-CA003-30GC User Manual

User Manual of Area Scan GigE Camera
10
1.3 Specifications
1.3.1 MV-CA003-30GM/GC Specification
Table 1-1 MV-CA003-30GM/GC Specification
Model
Parameters
MV-CA003-30GM
MV-CA003-30GC
0.3 MP 1/3" CMOS Machine Vision GigE Camera
Camera
Sensor Type
MT9V034
Sensor Size
1/3”
Resolution
752×480
Pixel Size
6 μm
Frame Rate
60fps
Dynamic Range
>52dB
SNR
>37dB
Gain
0-22dB
Exposure Time
32μs-1sec
Shutter Mode
Global shutter, supporting Auto, Manual, One-Push, etc. exposture modes.
Data Interface
Gigabit Ethernet
Digital I/O
Opto-isolated input x 1
Opto-isolated output x 1
Bi-directional non-isolated I/O x 1
Image Buffer
128MB
Data Format
Mono 8/10/10p/12/12p
Mono 8/10/12
Bayer BG 8/10/10p/12/12p
YUV 422 8, YUV 422 8 UYVY
RGB8
General
Power Supply and
Consumption
<2.5W@12VDC or PoE, voltage 5 to 15V
Temprature
Working Temprature 0°C to 50°C, Storage Temprature -30°C to 70°C
Dimension
29mm×29mm×42mm
Weight
≈68g

HIKVISION MV-CA003-30GC Specifications

General

Model	MV-CA003-30GC
Sensor Type	CMOS
Resolution	2048 x 1536
Frame Rate	30 fps
Lens Mount	C-Mount
Interface	GigE
Power Supply	12 VDC
Sensor Size	1/1.8 inch
