Figure 2-39 Remove the Trim Ring
4. Install the camera to the wall mount with three PA4
× 25 screws (supplied).
Figure 2-40 Install the Camera
5. Refer to steps 6 to 11 of 2.3.1 Ceiling Mounting
Without Junction Box to finish installation.
3 Menu Description
Please follow the steps below to call the menu.
Note:
The actual display may vary with your camera model.
Steps:
1. Connect the camera with the TVI DVR and the
monitor, as shown in figure 3-1.
Figure 3-1 Connection
2. Power on the camera, TVI DVR, and monitor to view
the image on the monitor.
3. Click PTZ Control to enter the PTZ Control interface.
4. Call the camera menu by clicking button or
calling preset No. 95.
