Hillyard TRIDENT V14D - Upper Housing

21HIL 56082 / HIL 56083 - Operators Manual - Trident V14D / V18D
Upper Housing
ITEM PART NO. REF NO. DESCRIPTION NOTES
1 86407650 1910ge Cable with US-Plug 3-wire, yellow FOR V14D
- 86407660 1918ge Cable VS18 - 17/3 AWG FOR V18D
2 86142050 1037ES Handle grip cpl., black
3 86142120 1596SW Handle cover cpl., black
4 86430880 10161ER Handle tube, 830mm
5 86430890 10152HY Dust bag housing BS 360/460,basalt gray/ light blue
6 86407700 1420SW Grommet, black
7 86430900 1966lb Switch button, light blue
8 86345570 1962 Spring
9 86430910 05114 Switch
10 86363610 1955 Switch holder
11 86349910 1956 Switch cover
12 86363620 1038bg Connecting tube, basalt gray
13 86144600 1792kg Retaining ring, karcher gray
14 86372770 1975ER Printed circuit board
14 86137760 835UL Antistatic-wire, blue, 250mm(8")
15 86137770 836UL Antistatic-wire, blue, 180mm(7")
16 86142810 1283UL Internal cable
17 86139110 1030UL Cable clamp
18 86145530 1026UL Switch cover cpl., black
19 86140990 1040 Dust bag lever
20 86144640 1041 Return spring
21 86143010 1027 Leaf spring
22 86140170 1025 Connecting rod
23 86139970 1073 Clamp
24 86143330 1044 Motor filter
25 86430920 1039HY Back cover cpl., gray black/light blue
26 86138010 1059 Back cover seal
27 86141890 1061 Gasket
28 86430930 1057LB Latch with spring and pin, light blue
29 86146340 1461gs Cable hook, grey black
30 86143160 1462GS Cable hook, turnable, grey black
31 86407790 1783KA Extension tube without hose cpl.
32 86430940 1776ER Catch incl. Leaf spring
33 86143020 1739ER Leaf Spring
34 86139590 1775kg Catch holder
35 86142640 1784sb Hose cpl., silver
36 86430950 10150HY Motor Housing, grey black, "TRIDENT"
37 86146200 1265UL Terminal Block cpl.
38 86431360 10117UL Female contact holder cpl.
39 86143090 1553 Locking Rod
40 86430960 0819gs Locking Catch cpl., dark gray
41 86430970 10106 Vacuum Motor Seal
42 86143660 7041ER Vacuum Motor,120V, 1000W, cpl.
43 86138380 05140S Carbon Brush Set Vacuum Motor
44 86430980 10118 Motor Support
45 86430990 10102UL Motor Locator
46 86431000 10101UL Air Duct
47 86431010 10120ER Silencer, 2 pcs.
48 86431020 10104sw Seal
49 86431030 10109ER Exhaust Filter
50 86431040 10103gs Exhaust Filter Cover, gray black
51 86196290 0101ER Screw C 3,9x9,5 Din 7981
52 86147030 0102ER Screw F 3,9x13
53 86147040 0103ER Screw C 3,9x16 Din 7981
54 86147070 0111ER Screw AM5x30 Din 7985
55 86146540 0140ER Washer 4,3
56 86284750 1055JE Dust Bag
