Power Head-V14D
ITEM PART NO. REF NO. DESCRIPTION NOTES
100 86407840 20200sw Chassis cpl., black
101 86363140 20204GS Front base plate cpl., gray black
102 86407850 20109SW Bumper, black
103 86363160 20115 Retaining bracket
104 86407860 20107GS Rear base plate, gray black
105 86363180 20230ER Foot pedal cpl., light gray/orange
105a 86378430 20140ER Axle
106 86363190 20136ER Internal plastic bearing
107 86406030 2306SW Wheel, black
108 86363200 2014ER Axle clamp
109 86363210 20126ER Pile adjustment axle
110 86407880 2608gs Wheel, pile adjustment, gray black
111 86146220 2833 Thrust member cpl.
112 86363220 20128ER Adjustment button, light gray
113 86145270 4019 Spring
114 86143500 2973ER Brush motor 120V, 175W
114a 86138390 05141S Pair of carbon brushes
115 86309030 2319 Motor pulley cpl.
116 86138220 2923 Belt
117 86431050 20271ER Swivel neck cpl.
118 86364770 0899ER Wire swivel neck, 3-wire
119 86145820 2530hg Swivel neck cover
120 86363260 20217ER Swivel neck support r.h. cpl.
121 86363270 20218ER Swivel neck support l.h. cpl.
122 86363710 0897ER Micro switch incl. wire
123 86145240 2546 Leaf spring
124 86139970 1073 Clamp
125 86363280 2919ER Brush pulley
126 86363720 20162ER Printed Circuit Board 120v 175w 14"
127 86363300 4098ER Brush assembly
128 86002440 2046 Brush strip
129 86363310 20123ER Bearing block l.h.
130 86407900 20117ER Bearing block r.h.
131 86431060 20120LB Brush roller release, light blue
131a 86363340 20121ER Spring
132 86431370 2256ER Support lever with spring
133 86345580 2651 Return spring
134 86431070 21220HY Power head cover V14D, cpl., gray black
135 86407930 20118EK Side plate, black
136 86144790 01017ER Screw STS 4x20
137 86144850 0197ER Screw 4x12
138 86363370 01036ER Screw 4 x14
139 86147170 0176ER Screw 4 x 30
140 86147030 0102ER Screw 3,9x13
141 86363390 20124ER Access door, orange
142 86363400 20127ER Axle adjustment lever
143 86363410 20129ER Mounting cap
