4. Technical data
Right of technical changes reserved.
Range of the points 30 m (98 ft)
Level of accuracy setting at room temperature +24
°C (75 °F)
1
±3.0 mm at 10 m (±¹/₈ in at 33 ft)
Self-leveling time
3 s (typical)
Laser class
Class 2, visible, 620 - 690 nm, ±10 nm (EN 60825-
1:2007 / IEC 60825 - 1:2007); class II (CFR 21
§1040 (FDA)
Beam diameter Distance 5 m: < 4 mm
Distance 20 m: < 16 mm
Self-leveling range
±4° (typical)
Automatic power-off Activated after: 15 min
Operating status indicator
LED and laser beams
Power supply AA‑size batteries, Alkaline batteries: 4
Battery life Alkaline battery 2,500 mAh, Temperature +24°C
(+75°F): 50 h (Typical)
Operating temperature range Min. -10°C / Max. +50°C (+14 to 122 °F)
Storage temperature Min. -25°C / Max. +63°C (-13 to 145 °F)
Dust and water spray protection (except battery
compartment)
IP 54 as per IEC 529
Tripod thread (tool)
UNC¹⁄₄"
Tripod thread (foot) BSW ⁵/₈" UNC ¹/₄"
Dimensions 63 x 107 x 137 mm (2 ¹/₂ x4¹/₄ x5³/₈ in)
Weight
With foot but without batteries: 0.49 kg (1.08 lbs)
1
Influences such as, in particular, high temperatures, moisture, shock, fall, etc. may lead to deviations from the level of accuracy which was set.
5. Safety instructions
WARNING: Ensure that you read all safety precau-
tions and instructions.Failure to observe the safety
precautions and instructions may result in electric
shock, fire and/or serious injury. Retain all safety
precautions and instructions for future reference. .
5.1 General safety rules
a) Check the accuracy of the tool before using it to
take measurements.
b) The tool and its ancillary equipment may
present hazards when used incorrectly by
untrained personnel or when used not as
directed.
c) To avoid the risk of injury, use only genuine
Hilti accessories and additional equipment.
d) Stay alert, watch what you are doing and use
common sense when operating the machine.
Don’t use the machine when you are tired or
under the influence of drugs, alcohol or med-
ication. A moment of inattention while operating
machines may result in serious personal injury.
e) Modification of the tool is not permissible.
f) Observe the information printed in the operat-
ing instructions concerning operation, care and
maintenance.
g) Do not render safety devices ineffective and do
not remove information and warning notices.
h) Keep laser tools out of reach of children.
i) Take the influences of the surrounding area into
account. Do not expose the tool to rain or snow
en
14
