4. Technical data
NOTE
Right of technical changes reserved.
Range of the points
30 m
Range of the lines and intersection point
10 m
Accuracy of the points Distance 10 m (30 ft): ±3 mm (±¹/₈ in)
Accuracy of the laser lines Length of the lines 10 m (30 ft): ±1.5 mm (±¹/₁₆ in)
Self-leveling time
5s
Laser class
Class 3R: EN 60825‑01:2003; IEC 825‑ 1:2003;
Class IIIa: CFR 21 § 1040 (FDA)
Beam diameter (lower beam) Distance 5 m: < 5 mm
Distance 20 m: < 20 mm
Beam diameter (other beams) Distance 5 m: < 4 mm
Distance 20 m: < 16 mm
Line width Distance 5 m: < 2.2 mm
Self-leveling range
±3.5°
Automatic power-off Activated after: 15 min
Operating status indicator
LED and laser beams
Power supply AA‑size batteries, Alkaline batteries: 4
Battery life (2 points and 1 line) Alkaline battery 2,500 mAh, Temperature 25°C
(+77°F): 40 h
Operating temperature range Min. ‑10°C / Max. 50°C (+14 to 122°F)
Storage temperature Min. ‑20°C / Max. 63°C (-4 to 145°F)
Dust and water spray protection (except battery
compartment)
IP 54
IEC 529
Tripod thread
BSW⁵⁄₈"UNC¹⁄₄"
Weight Without batteries: 0.66 kg
Dimensions Foot in the closed position: 138 mm X 51 mm X
89 mm
Foot in the open position: 164 mm X 51 mm X
126 mm
5. Safety rules
In addition to the information relevant to safety
given in each of the sections of these operating
instructions, the following points must be strictly
observed at all times.
5.1 General safety rules
a) Check the accuracy of the tool before using it to
take measurements.
b) The tool and its ancillary equipment may present
hazards when used incorrectly by untrained per-
sonnel or when used not as directed.
c) To avoid the risk of injury, use only genuine Hilti
accessories and additional equipment.
d) Do not open the casing of the tool.
e) Modification of the tool is not permissible.
f) Observe the information printed in the operat-
ing instructions concerning operation, care and
maintenance.
g) Do not render safety devices ineffective and do
not remove information and warning notices.
h) Keep laser tools out of reach of children.
en
17
