17
7. Operation
7.1.5 Deactivating the automatic switch-off function
1. Press and hold the selector button (approx. 4
seconds) until the laser beam blinks three times in
confirmation.
-NOTE-
The tool will then operate until switched off by
pressing the selector button or until the batteries
are exhausted.
7.2. Examples of applications within the self-leveling range
7.2.1 Example 1:
Mounting shelves on a wall
1. Set up the tool on a telescopic pole, frame clamp or
tripod.
2. Switch on the horizontal beam.
3. Adjust the height of the tool until the beam is at the
correct position.
4. Mount the shelves along the laser line.
7.2.2 Example 2:
Mounting cable trays on a wall
1. Set up the tool on a telescopic pole or tripod.
2. Switch on the horizontal beam.
To Next Page
