Hilti RT 6-A22 User Manual

6 English 2225142
*2225142*
3.4 Lithiumion battery status display
The Li-ion battery state of charge and malfunctions of the power tool are indicated by the display on the Liion
battery. The Liion battery state of charge is displayed after pressing one of the two battery release buttons.
Status Meaning
4 LEDs light. State of charge: 75 % to 100 %
3 LEDs light. State of charge: 50 % to 75 %
2 LEDs light. State of charge: 25 % to 50 %
1 LED lights. State of charge: 10 % to 25 %
1 LED flashes. State of charge: < 10 %
1 LED flashes, the power tool is not in working or-
der.
The battery has overheated or is completely dis-
charged.
4 LEDs flash, the power tool is not in working or-
der.
The power tool is overloaded or has overheated.
Battery state of charge cannot be displayed while the control switch is pressed and for up to 5 seconds
after releasing the control switch.
If the battery display LEDs flash, please observe the instructions given in the Troubleshooting section.
3.5 Overload protection
If an overload occurs the tool switches off automatically and the overload LED flashes for 10 seconds.
The tool cannot be used during this time. Overloading is generally caused by residues in the jaw
mechanism, which has to be cleaned accordingly. Follow the instructions on removing residues in the
section on care and maintenance. The tool should start working again once the blockage has been
removed.
4 Technical data
RT 6-A22
Rated voltage
21.6 V
Weight including battery B22⁄8.0
2.7 kg
(6.0 lb)
Stroke length
25 mm
(1.0 in)
4.1 Battery
Battery operating voltage
21.6 V
Ambient temperature for operation
−17 ℃ … 60 ℃
(1 ℉ … 140 ℉)
Storage temperature
−20 ℃ … 40 ℃
(−4 ℉ … 104 ℉)
Battery charging starting temperature
−10 ℃ … 45 ℃
(14 ℉ … 113 ℉)
4.2 Table correlating nosepieces and blind rivets to be used
Nosepiece designation Blind rivet diameter, all commercially available
materials
RTN 2.4, NP 2.4 2.4 mm (3⁄32")
RTN 3.2, NP 3.2 3.2 mm (1⁄8")
RTN 4.0, NP 4.0 4 mm (5⁄32")
RTN 4.8, NP 4.8 4.8 mm (3⁄16")

Hilti RT 6-A22 Specifications

General

Type	Hand gun
Product color	Black, Red
Rivet sizes supported	2.4, 3.2, 4, 4.8, 5 mm
Mandrel diameter range	2.4 - 5 mm
Country of origin	Germany
Power source	Battery
Battery voltage	22 V
Quantity per shipping (inner) case	1 pc(s)
Battery included	No

Weight and Dimensions

Height	286 mm
Weight	1650 g
Package depth	433 mm
Package width	2076 mm
Package height	400 mm
Package weight	3055 g
